Layers in Storage – For better or worse

Storage arrays and storage services are built upon by layers and layers beneath its architecture. The physical components of hard disk drives and solid states are abstracted into RAID volumes, virtualized into other storage constructs before they are exposed as shares/exports, LUNs or objects to the network.

Everyone in the storage networking industry, is cognizant of the layers and it is the foundation of knowledge and experience. The public cloud storage services side is the same, albeit more opaque. Nevertheless, both have layers.

In the early 2000s, SNIA® Technical Council outlined a blueprint of the SNIA® Shared Storage Model, a framework describing layers and properties of a storage system and its services. It was similar to the OSI 7-layer model for networking. The framework helped many industry professionals and practitioners shaped their understanding and the development of knowledge in their respective fields. The layering scheme of the SNIA® Shared Storage Model is shown below:

SNIA Shared Storage Model – The layering scheme

Storage vendors layering scheme

While SNIA® storage layers were generic and open, each storage vendor had their own proprietary implementation of storage layers. Some of these architectures are simple, but some, I find a bit too complex and convoluted.

Here is an example of the layers of the Automated Volume Management (AVM) architecture of the EMC® Celerra®.

EMC Celerra AVM Layering Scheme

I would often scratch my head about AVM. Disks were grouped into RAID groups, which are LUNs (Logical Unit Numbers). Then they were defined as Celerra® dvols (disk volumes), and stripes of the dvols were consolidated into a storage pool.

From the pool, a piece of a storage capacity construct, called a slice volume, were combined with other slice volumes into a metavolume which eventually was presented as a file system to the network and their respective NAS clients. Explaining this took an effort because I was the IP Storage product manager for EMC® between 2007 – 2009. It was a far cry from the simplicity of NetApp® ONTAP 7 architecture of RAID groups and volumes, and the WAFL® (Write Anywhere File Layout) filesystem.

Another complicated layered framework I often gripe about is Ceph. Here is a look of how the layers of CephFS is constructed.

Ceph Storage Layered Framework

I work with the OpenZFS filesystem a lot. It is something I am rather familiar with, and the layered structure of the ZFS filesystem is essentially simpler.

Storage architecture mixology

Engineers are bizarre when they get too creative. They have a can do attitude that transcends the boundaries of practicality sometimes, and boggles many minds. This is what happens when they have their own mixology ideas.

Recently I spoke to two magnanimous persons who had the idea of providing Ceph iSCSI LUNs to the ZFS filesystem in order to use the simplicity of NAS file sharing capabilities in TrueNAS® CORE. From their own words, Ceph NAS capabilities sucked. I had to draw their whole idea out in a Powerpoint and this is the architecture I got from the conversation.

There are 3 different storage subsystems here just to provide NAS. As if Ceph layers aren’t complicated enough, the iSCSI LUNs from Ceph are presented as Cinder volumes to the KVM hypervisor (or VMware® ESXi) through the Cinder driver. Cinder is the persistent storage volume subsystem of the Openstack® project. The Cinder volumes/hypervisor datastore are virtualized as vdisks to the respective VMs installed with TrueNAS® CORE and OpenZFS filesystem. From the TrueNAS® CORE, shares and exports are provisioned via the SMB and NFS protocols to Windows and Linux respectively.

It works! As I was told, it worked!

A.P.P.A.R.M.S.C. considerations

Continuing from the layered framework described above for NAS, other aspects beside the technical work have to be considered, even when it can work technically.

I often use a set of diligent data storage focal points when considering a good storage design and implementation. This is the A.P.P.A.R.M.S.C. Take for instance Protection as one of the points and snapshot is the technology to use.

Snapshots can be executed at the ZFS level on the TrueNAS® CORE subsystem. Snapshots can be trigged at the volume level in Openstack® subsystem and likewise, rbd snapshots at the Ceph subsystem. The question is, which snapshot at which storage subsystem is the most valuable to the operations and business? Do you run all 3 snapshots? How do you execute them in succession in a scheduled policy?

In terms of performance, can it truly maximize its potential? Can it churn out the best IOPS, and deliver at wire speed? What is the latency we can expect with so many layers from 3 different storage subsystems?

And supporting this said architecture would be a nightmare. Where do you even start the troubleshooting?

Those are just a few considerations and questions to think about when such a layered storage architecture along. IMHO, such a design was over-engineered. I was tempted to say “Just because you can, doesn’t mean you should

Elegance in Simplicity

Einstein (I think) quoted:

Einstein’s quote on simplicity and complexity

I am not saying that having too many layers is wrong. Having a heavily layered architecture works for many storage solutions out there, where they are often masked with a simple and intuitive UI. But in yours truly point of view, as a storage architecture enthusiast and connoisseur, there is beauty and elegance in simple designs.

The purpose here is to promote better understanding of the storage layers, and how they integrate and interact with each other to deliver the data services to the network. In the end, that is how most storage architectures are built.



Do we still need FAST (and its cohorts)?

In a recent conversation with an iXsystems™ reseller in Hong Kong, the topic of Storage Tiering was brought up. We went about our banter and I brought up the inter-array tiering and the intra-array tiering piece.

After that conversation, I started thinking a lot about intra-array tiering, where data blocks within the storage array were moved between fast and slow storage media. The general policy was simple. Find all the least frequently access blocks and move them from a fast tier like the SSD tier, to a slower tier like the spinning drives with different RPM speeds. And then promote the data blocks to the faster media when accessed frequently. Of course, there were other variables in the mix besides storage media and speeds.

My mind raced back 10 years or more to my first encounter with Compellent and 3PAR. Both were still independent companies then, and I had my first taste of intra-array tiering

The original Compellent and 3PAR logos

I couldn’t recall which encounter I had first, but I remembered the time of both events were close. I was at Impact Business Solutions in their office listening to their Compellent pitch. The Kuching boys (thank you Chyr and Winston!) were very passionate in evangelizing the Compellent Data Progression technology.

At about the same time, I was invited by PTC Singapore GM at the time, Ken Chua to grace their new Malaysian office and listen to their latest storage vendor partnership, 3PAR. I have known Ken through my NetApp® days, and he linked me up Nathan Boeger, 3PAR’s pre-sales consultant. 3PAR had their Adaptive Optimization (AO) disk tiering and Dynamic Optimization (DO) technology.

Continue reading

Discovering OpenZFS Fusion Pool

Fusion Pool excites me, but unfortunately this new key feature of OpenZFS is hardly talked about. I would like to introduce the Fusion Pool feature as iXsystems™ expands the TrueNAS® Enterprise storage conversations.

I would not say that this technology is revolutionary. Other vendors already have the similar concept of Fusion Pool. The most notable (to me) is NetApp® Flash Pool, and I am sure other enterprise storage vendors have the same. But this is a big deal (for me) for an open source file system in OpenZFS.

What is Fusion Pool  (aka ZFS Allocation Classes)?

To understand Fusion Pool, we have to understand the basics of the ZFS zpool. A zpool is the aggregation (borrowing the NetApp® terminology) of vdevs (virtual devices), and vdevs are a collection of physical drives configured with the OpenZFS RAID levels (RAID-0, RAID-1, RAID-Z1, RAID-Z2, RAID-Z3 and a few nested RAID permutations). A zpool can start with one vdev, and new vdevs can be added on-the-fly, expanding the capacity of the zpool online.

There are several types of vdevs prior to Fusion Pool, and this is as of pre-TrueNAS® version 12.0. As shown below, these are the types of vdevs available to the zpool at present.

OpenZFS zpool and vdev types – Credit: Jim Salter and Arstechnica

Fusion Pool is a zpool that integrates with a new, special type of vdev, alongside other normal vdevs. This special vdev is designed to work with small data blocks between 4-16K, and is highly efficient in handling random reading and writing of these small blocks. This bodes well with the OpenZFS file system metadata blocks and other blocks of small files. And the random nature of the Read/Write I/Os works best with SSDs (can be read or write intensive SSDs).

Continue reading

Fueling the Flywheel of AWS Storage

It was bound to happen. It happened. AWS Storage is the Number 1 Storage Company.

The tell tale signs were there when Silicon Angle reported that AWS Storage revenue was around USD$6.5-7.0 billion last year and will reach USD$10 billion at the end of 2021. That news was just a month ago. Last week, IT Brand Pulse went a step further declaring AWS Storage the Number 1 in terms of revenue. Both have the numbers to back it up.

AWS Logo

How did it become that way? How did AWS Storage became numero uno?

Flywheel juggernaut

I became interested in the Flywheel concept some years back. It was conceived in Jim Collins’ book, “Good to Great” almost 20 years ago, and since then, Amazon.com has become the real life enactment of the Flywheel concept.

Amazon.com Flywheel – How each turn becomes sturdier, brawnier.

Every turn of the flywheel requires the same amount of effort although in the beginning, the noticeable effect is minuscule. But as every turn gains momentum, the returns of each turn scales greater and greater to the fixed efforts of operating a single turn.

Continue reading

Ransomware recovery with TrueNAS ZFS snapshots

This is really an excuse to install and play around with TrueNAS® CORE 12.0.

I had a few “self assigned homework exercises” I have to do this weekend. I was planning to do a video webcast with an EFSS vendor soon, and the theme should be around ransomware. Then one of the iXsystems™ resellers, unrelated to the first exercise, was talking about this ransomware messaging yesterday after we did a technical training with them. And this weekend is coming on a bit light as well. So I thought I could bring all these things, including checking out the TrueNAS® CORE 12.0, together in a video (using Free Cam), of which I would do for the first time as well. WOW! I can kill 4 birds with one stone! All together in one blog!

It could be Adam Brown 89 or worse

Trust me. You do not want AdamBrown89 as your friend. Or his thousands of ransomware friends.

When (not if) you are infected by ransomware, you get a friendly message like this in the screenshot below. I got this from a local company who asked for my help a few months ago.

AdamBrown89 ransomware message

AdamBrown89 ransomware message

I have written about this before. NAS (Network Attached Storage) has become a gold mine for ransomware attackers, and many entry level NAS products are heavily inflicted with security flaws and vulnerabilities. Here are a few notable articles in year 2020 alone.

Continue reading

OpenZFS 2.0 exciting new future

The OpenZFS (virtual) Developer Summit ended over a weekend ago. I stayed up a bit (not much) to listen to some of the talks because it started midnight my time, and ran till 5am on the first day, and 2am on the second day. Like a giddy schoolboy, I was excited, not because I am working for iXsystems™ now, but I have been a fan and a follower of the ZFS file system for a long time.

History wise, ZFS was conceived at Sun Microsystems in 2005. I started working on ZFS reselling Nexenta in 2009 (my first venture into business with my company nextIQ) after I was professionally released by EMC early that year. I bought a Sun X4150 from one of Sun’s distributors, and started creating a lab server. I didn’t like the workings of NexentaStor (and NexentaCore) very much, and it was priced at 8TB per increment. Later, I started my second company with a partner and it was him who showed me the elegance and beauty of ZFS through the command lines. The creed of ZFS as a volume and a file system at the same time with the CLI had an effect on me. I was in love.

OpenZFS Developer Summit 2020 Logo

OpenZFS Developer Summit 2020 Logo

Exciting developments

Among the many talks shared in the OpenZFS Developer Summit 2020 , there were a few ideas and developments which were exciting to me. Here are 3 which I liked and I provide some commentary about them.

  • Block Reference Table
  • dRAID (declustered RAID)
  • Persistent L2ARC

Continue reading

A Paean to NFS

It is certainly encouraging to see both NAS protocols, NFS and SMB, featured well in the latest VMware® vSAN 7 Update 1 release. The NFS v3 and v4.1 support was already in vSAN 7.0 when it was earlier announced as part of its Native File Services for vSAN. But some years ago, NFS was not always the primary storage protocol of choice. SAN protocols, Fibre Channel and iSCSI, were almost always designated to serve enterprise applications. At the client side, Windows became prominent, and the SMB/CIFS protocol dominated the landscape of the desktop. This further pushed NFS into the back closet.

NFS or Network File System has its naysayers. The venerable, but often maligned distributed network file protocol is 36 years today. In storage vendors such as NetApp®, VAST Data, Pure Storage FlashBlade, and Dell EMC Isilon, NFS is still positioned as the primary file protocol for manufacturing testers on the shop floor, EDA/eCAD applications, seismic and subsurface applications in Oil & Gas and many more. In another development, just like its presence in the vSAN Native Services,, NFS has also quietly embedded itself into many storage platforms to serve the data platform services within the respective framework itself.

And I have experienced NFS from the client side to the enterprise applications and more, and I take this opportunity to pay tribute.

NFS (Network File System) client server network

NFS (Network File System) client server network

Continue reading

Give back or no give

[ Disclosure: I work for iXsystems™ Inc. Views and opinions are my own. ]

If my memory served me right, I recalled the illustrious leader of the Illumos project, Garrett D’Amore ranting about companies, big and small, taking OpenZFS open source codes and projects to incorporate into their own technology but hardly ever giving back to the open source community. That was almost 6 years ago.

My thoughts immediately go back to the days when open source was starting to take off back in the early 2000s. Oracle 9i database had just embraced Linux in a big way, and the book by Eric S. Raymond, “The Cathedral and The Bazaar” was a big hit.

The Cathedral & The Bazaar by Eric S. Raymond

Since then, the blooming days of proprietary software world began to wilt, and over the next twenty plus year, open source software has pretty much taken over the world. Even Microsoft®, the ruthless ruler of the Evil Empire caved in to some of the open source calls. The Microsoft® “I Love Linux” embrace definitely gave the victory feeling of the Rebellion win over the Empire. Open Source won.

Open Source bag of worms

Even with the concerted efforts of the open source communities and projects, there were many situations which have caused frictions and inadvertently, major issues as well. There are several open source projects licenses, and they are not always compatible when different open source projects mesh together for the greater good.

On the storage side of things, 2 “incidents” caught the attention of the masses. For instance, Linus Torvalds, Linux BDFL (Benevolent Dictator for Life) and emperor supremo said “Don’t use ZFS” partly due to the ignorance and incompatibility of Linux GPL (General Public License) and ZFS CDDL (Common Development and Distribution License). That ruffled some feathers amongst the OpenZFS community that Matt Ahrens, the co-creator of the ZFS file system and OpenZFS community leader had to defend OpenZFS from Linus’ comments.

Continue reading

FreeNAS 11.2 & 11.3 eBook

[ Full disclosure: I work for iXsystems™ Inc. This eBook was 3/4 completed when I joined on July 1, 2020 ]

I am releasing my FreeNAS™ eBook today. It was completed about 4 weeks ago, but I wanted the release date to be significant which is August 31, 2020.

FreeNAS logo

Why August 31st? Because today is Malaysia’s Independence Day.

Why the book?

I am an avid book collector. To be specific, IT and storage technology related books. Since I started working on FreeNAS™ several years ago, I wanted to find a book to learn. But the FreeNAS™ books in the market are based on an old version of FreeNAS™. And the FreeNAS™ documentation is a User Guide where it explains every feature without going deeper with integration of real life networking services, and situational applications such as SMB or NFS client configuration.

Since I have been doing significant amount of feature “testings” of FreeNAS™ from version 9.10 till the present version 11,3 on Virtualbox™, I have decided to fill that gap. I have decided to write a cookbook-style FreeNAS™ on Virtualbox™ that covers most of the real-life integration work with various requirements including Active Directory, cloud integration and so on. All for extending beyond the FreeNAS™ documentation.

Continue reading
